Monday, June 23, 2014

SmartPurger 3.6 - batch processing for AutoCAD

SmartPurger 3.6 comes with support for Autodesk AutoCAD 2015 and the new Orphaned Data purge (remains from MicroStation DGN linetypes)  and support for sharepoint folder locations.

SmartPurger is a batch and script utility for processing multiple AutoCAD drawings with full control. Execute LSP or SCR files on multiple drawings. SmartPurger handles crashes so the AutoCAD batch processing continues to the end and leaves bad drawings to be corrected manually if needed. Many purge and cleanup settings are available.

The free trial is fully functional except that you can only batch process 10 drawings per session to give you the chance to confirm that the program works as expected. When you purchase you can use SmartPurger with no limitations.

Check out more about SmartPurger here.

Tuesday, April 1, 2014

Autodesk AutoCAD 2015 trial available

Autodesk AutoCAD 2015 was released last week and now available as trial too.

As you can see AutoCAD has a new updated look with a the theme darker. There are also several nice new features to consider. I’m updating the page about AutoCAD 2015 so it’s not yet complete and I’ll post more about it later on too.

Most JTB World’s apps will just work with AutoCAD 2015 as they are and where needed they soon will be updated to work fully with AutoCAD 2015.

Tuesday, March 25, 2014

DWG TrueView 2015 can remove educational plot stamps

If you visit www.autodesk.com/trueview you will find that the English version of Autodesk DWG TrueView 2015 now is available for download. Note that only Windows 7, Windows 8 and Windows 8.1 are supported operating systems.

Direct links to download:

DWG TrueView 2015

By default there is a dark color scheme and some icons have an updated look. Layout Tabs is a new icon that lets you display or hide layout and model tabs. The status bar where the coordinates are is now on the same row as the layout tabs.

The “New Tab” lets you open files and access Recent Documents.

In DWG Convert Modify Conversion Setup, “Remove Design Feed” is a new option.

DWG Convert 2015 Setup Settings

In the post AutoCAD Educational Version - Plot Stamp Not Detected! I speculated that “Autodesk DWG TrueView 2015 and DWG Convert to batch re-save drawings to get rid of the stamp.” and after testing I can verify that DWG Convert now remove the educational plot stamp just by re-saving the drawings. If you want to know if you have any of these infected drawings in your network use JTB World’s EduFinder.

Goodbye to  “Educational Version - Plot Stamp Detected This drawing will display the message, "PRODUCED BY AN AUTODESK EDUCATIONAL PRODUCT," Do you want to continue? If you continue, the message will mark this drawing and any drawings that reference it.”

SMS and SCCM Integration ReadMe
Improvements in Autodesk® deployment technology allow many administrators to streamline their process of integrating Autodesk deployments on Microsoft® Systems Management Server (SMS) and System Center Configuration Manager (SCCM). In most cases, Autodesk deployments can now be advertised using a single program line instead of individual program lines for each component in the deployment.
To advertise a deployment with a single program line, use the following syntax:
.\Img\Setup.exe /W /Q /I .\Img\<deployment name>.ini /language en-us
This sample command line assumes that the package contents are defined at the root folder of your Autodesk product deployment folder, and that the product language is US English (en-us). If you have created a combined deployment and you would like to advertise it, use the following syntax:
.\img\Setup.exe /w /x86 <adminImage's name> /x64 <adminImage's name>

Software Requirements
Before creating an SCCM advertisement, ensure that all target computers have Microsoft .NET 4.0 Framework installed. Windows XP computers need Direct X installed prior to receiving a 2011 or later Autodesk product advertisement.

Component-level Advertisement
Special circumstances such as execution time limits may require you to advertise an Autodesk deployment at the component level. Please refer to <deployment name>_SCCM.txt for a listing of required program lines in the order they must occur on target computers. These commands will vary by deployment. For long command lines, use a batch file.

See also this post on install/uninstall.

This gives us an early sneak peek of what AutoCAD 2015  will look like. If you wonder about its system requirements they are already available here. You also find that AutoCAD 2015 is the only version officially supporting Windows 8.1 at this point.

I’ve also heard that Autodesk Subscription downloads already have 2015 available as well as the news that Network Licensing for AutoCAD LT 2015 is available and thus JTB FlexReport will also be able to monitor these FlexNet-based network licenses.

If you want to compare 2015 to what DWG TrueView 2014 looks like.

Monday, March 24, 2014

AutoCAD 2014 for Mac Service Pack 1

AutoCAD 2014 for Mac Service Pack 1 is available here and AutoCAD LT 2014 for Mac Service Pack 1 is available here.

Readme details about AutoCAD 2014 for Mac Service Pack 1:

Problems Reported with the Customer Error Reporting Utility
As a result of detailed information from customers who used the Customer Error Reporting (CER) utility, a number of problems were identified and fixed. Updates have been made to the following features:
Block
-Crash when making blocks in some situation.
Copy/paste
-Crash when copy/paste in some drawings.
Drafting
-Random crash during drawing and editing.
Startup
-Crash at startup due to some user profiles missing.
-Random crash at startup when getting the Displcay Card infomation.
View
-Crash when click the viewport control label.

The following general changes and improvements have been made:
AutoCAD LT
-Align command missing in LT.
-Image underlay shows twisted or white/black bands when zooming in canvas.
License
-Cannot activate AutoCAD with some suite serial number, like Education Master suite serial number.
Other
-System animation(scrolling or switching desktop) glitches after force quit AutoCAD in some situation.
-Typo in lynda.com link in AutoCAD.
-Mis-use of Lucida Grande font.
Plot
-AutoCAD hangs when plotting drawings in some situation.
-Plot stamp now shows the system time on local machine.
-Image underlay is not fully displayed in plotted result.

And an enhancement: Now you can Reset AutoCAD at startup by holding Shift+click AutoCAD(or AutoCAD LT) icon. This helps in the case when you cannot start AutoCAD normally.

More about AutoCAD for Mac.

Friday, February 7, 2014

Why there is no Autodesk Design Review 2014

You may wonder why there is no Autodesk Design Review 2014 (ADR 2014). On the Autodesk Labs blog you got the answer:

  • DWF is definitely NOT dead.

  • We are investing significant resources on a cloud solution that will allow the sharing of models without sharing the source. This solution will also build collaboration tools because that is one of the strengths of a cloud solution.

  • To prove that we are strongly investing into DWF, we already are loading bigger DWF files than ADR can and will be making them available to the workflow of the cloud applications like Autodesk 360, Fusion 360, etc. AutoCAD WS is planning the same for the 2D side of things. Eventually they will merge into Autodesk 360 viewing that covers both aspects.

  • ADR will have less and less value as the cloud solution matures.

  • The cloud solution is being built in stages and handling larger DWF files is part of that roadmap. Our cloud-teams are looking at Customer Improvement Program (CIP) data from ADR on the most commonly used ADR features today. This will guide their efforts in rounding out our cloud functionality.

So in the meantime Autodesk Design Review 2013 is available and can be used.

You can also read on this post why Autodesk Freewheel was shut down.

Monday, February 3, 2014

AutoCAD Architecture Detail Components problem and solution

Do you have problem in Autodesk AutoCAD Architecture to open the Detail Component Manager or using any of the tools on the Tool Palettes - Design Details tab?

Maybe you get this error message showing up one or many times?

“Cannot open database C:\ProgramData\Autodesk\ACA 2014\enu\Details\Details (Global)\AecDtlComponents (Global).mdb.” followed by “Unable to execute the tool. Unspecified error.” and on the command line “ERROR: No database information found!” It might also show ACA 2013 or ACA 2012 or older. The file can also be for example AecDtlComponents (US).mdb or AecDtlComponents (UK).mdb.

Still if you try to open the mdb file manually it works fine.

But there is a solution available. This fix only applies to if you run a 64-bit version of AutoCAD Architecture.

SOLUTION: Download this Detail_Component_Manager_Fix.reg file and run it and you probably also need to answer yes a couple of times so it is merged into the Windows Registry. After that you should be able to use the tools as normal. No need to even restart AutoCAD Architecture.

Tools affected are Metal Runner, Metal Stud, Wood Stud, Hat Channel, Gypsum Board, Batt Insulation, Rigid Insulation, Brick, Concrete Block, Plywood, Protection Board, Roof Hatch, Roof Drain, Floor Drain, Sliding Door Head, HM Door Frame, Carpet, Stone Pavers, Recessed Light, Steel, Concrete Column, Earth Hatch and possibly some others.

Monday, January 20, 2014

Updates for Inventor and other Autodesk News and Tips

Here’s some recent links that can be useful.

Update 2 for Inventor 2014 Service Pack 1 - DL22744369

Update 4 for Inventor 2013 Service Pack 2 - DL22744178

Autodesk Privacy Statement was updated March 19, 2013

Crash when launch Autodesk software on Windows 8.1 with dual video cards where one is Intel HD Graphics 4000 - DL22827547

MrSID (4th gen) crashes AutoCAD - TS22852592
When you try to insert or connect to a MrSID (*.sid) file in AutoCAD Map 3D, Civil 3D, or Raster Design, the software crashes with a Fatal Error.
4th generation MrSID images are not yet supported by AutoCAD-based products.

“An error occurred attempting to create the transmittal. Please make sure the target location is writable and that the target disk has sufficient space.” - TS22852599

Error: "There was a problem adding data to Map" when connecting to WMS in Civil 3D or Map 3D - TS22852604

When using Parallels on Mac, the activation screen displays large overlapping text - GS22859328

How to Create the SCCM Software Installation Package - TS22029889

How to remove files left after a failed AutoCAD installation - TS21942335

How to repair an AutoCAD installation - TS22857015

Creating a layout profile, grips become offset from the crosshairs - TS22859189

Raster Design does not start if Windows roaming profiles are used - TS22859271

Modeling Operation Error: Missing double in restore file - TS22859321

Geomap function does not show a map - TS22859310

WMS not visible in AutoCAD Map - TS22859275

Slow performance when switching between layouts - TS22859315

Geotechnical Module: After importing borehole data all results seem to be scaled - TS22859305

Error: This drawing was created with a newer version of Civil 3D - TS22859326

Error: 1: 5 2: adlmPITSetProductInformation failed. 3: 2 + Security Permissions - Up and Ready

Monday, January 13, 2014

SmartPurger 3.5 released

SmartPurger 3.5 from JTB World is now available both from our product page as well as on Autodesk Exchange Apps. A free trial is available of SmartPurger so you can give it a try.

SmartPurger not only purges multiple drawings but can also batch process most anything you like if you have any Script or AutoLISP files you want to run on a bunch of DWGs. If you don’t know how we can help to create it so you can automate your manual tasks. An AutoCAD based application is required to run SmartPurger but it can also work with other DWG compatible CAD applications.

These are the bug fixes for this release:

-Fixed a bug where accoreconsole did not save to specified DWG version
-Purge multileader styles bug fixed where it did not always purge these styles.
-Handle dialog box about VBA not installed
-Fixed bug where Educational Version - Terminated sometimes show up in status column even though the drawing is not educational

If you are interested in other useful AutoCAD helper functions take a look at JTB Sheet Set Creator, DigSigStamp,Batch Publish for AutoCAD, DimensionPatrol, TransTips or OffsetInXref.

If you need any custom app created, small or large, for AutoCAD or Revit you are welcome to contact us.

Tuesday, January 7, 2014

AutoCAD P&ID 2014 Service Pack 1, Autodesk Beta, News and Hotfixes

Anyone with an Autodesk account can access the entire library of video recordings and class handouts from more than 600 classes from AU 2013 in Las Vegas—for free at the AU website, login and click on Classes on Demand.

Autodesk Completes Acquisition of Circuits.io (Autodesk 123D Circuits) - press release

Autodesk Beta Season is in Full Swing - Do you want to test & help improve the next versions of Autodesk products? https://beta.autodesk.com/. If history is followed future products can be AutoCAD 2015, Revit 2015 and so on.

Inventor 2014 SP1 crash on Start-up Windows 8.1 with Intel HD Graphics 4000 - Up and Ready

Working with Inventor and antivirus software - TS22811064
When you work with Inventor and there is antivirus software active on your machine, you may experience slow performance. For example, you may have slow response times while using Inventor and the refresh of Inventor UI may be slow. This is caused by antivirus software and you would like to optimize your performance.

Hotfix: Fix Fillet Translation, Punch Note Untranslation in Inventor 2013/2014 - DL22823934

Hotfix: Correct issue with “Cut” feature which cannot be selected in a “Pattern” operation in Inventor 2014 - DL22823063

Hotfix: Fix incorrect hotkey issue for command “Delete” in context menu in Inventor 2013 - DL22823494

Hotfix: Correct untranslation of column headers in sheet metal column headers in Inventor 2012/2013 - DL22823919

Sites disappear, but feature lines remain until audit in AutoCAD Civil 3D 2014 - TS22811035
Sites are disappearing from the drawing, but the Feature Lines remain. When you run AUDIT or RECOVER, the Feature Lines then disappear.

Direction in Object Viewer does not match UCS in AutoCAD Civil 3D - TS22813499

Xrefed survey figures plot with the wrong plot style in Civil 3D 2013 - TS22814640

Error: "Please wait while Windows configures AutoCAD Raster Design" - TS22817946

Wipeout draw order is not working with viewports - TS22817919

Error: "Not enough free RAM for HIDE--some lines will be hidden incorrectly" - TS22824497

AutoCAD P&ID 2014 Service Pack 1 - DL22757675
This Service Pack does not apply to AutoCAD Plant 3D 2014 Extensions 1 or 2 (Subscription). The updates in this Service Pack are included in Extension 2. AutoCAD 2014 Service Pack 1 is included in this service pack.

Issues fixed with this Service Pack:

P&ID Drawings

  • A new slregroup command has been added to make it easier to manage line groups. For more information, see About P&ID Line (SLINE) Grouping.
  • The Edit Sline Group... command was not available in the shortcut menu.
  • Control valve substitution did not work. If the substitution palette does not display correctly, you can erase and replace the control valve.

Customer Reported (CER) Defects

3D Model

  • File open command would fail when a drawing is opened that contains custom entities with embedded 3D solids.
  • Return bends would not always align with routed pipe.
  • Parts created with plantpartconvert could not be selected in the Spec Editor.
  • Ladders and structure did not always display correctly in an Ortho view.
  • Butterfly valves placed into a short pipe segment could cause the program to shut down unexpectedly.

Isometric Drawings

  • Splitting at a branch would sometimes place components outside the draw-area.
  • Tap weld was assigned to the same line number as the olet.
  • Improvements to isometric drawings including annotation and dimension placement.

Spec Editor

  • Flange thickness in inches did not update correctly for metric projects.

Tuesday, December 17, 2013

How to recover and fix problematic or corrupt DWGs in AutoCAD

This is a great resource for AutoCAD users. Troubleshooting corrupt DWG files - TS22753433

Usually there is a way to correct drawings with technical problems.

Issue
An AutoCAD DWG file cannot be opened and causes AutoCAD to show error messages or alerts, or to freeze or crash.

Open Drawing - Damaged File - The drawing file requires recovery. Errors were detected in the drawing. The file cannot be opened without being recovered.

The drawing file requires recovery.

Drawing file is not valid.

Drawing file is not valid.

Cause
Possible causes of file corruption:

  • Network (transmission errors, file locking, latent writing of data)
  • Storage media degradation (bad sectors on a hard drive)
  • Defective or failing RAM
  • Operating system issues
  • Power surges
  • 3rd - party applications running inside the Autodesk product
  • DWGs created or saved by non-Autodesk non-RealDWG products
  • AutoCAD terminated while saving DWG (less frequent)

Recommendation: Audit and purge before saving

Solution
If a file cannot be opened, take the following steps:

  • RECOVER command
    --Recovers a selected drawing file
    --If successful, open and run AUDIT command
    --Evaluates drawing integrity and possibly more error correction
    --Set system variable AUDITCTL=1 to create a report of audit results

The drawing file was recovered.

  • RECOVERALL command (introduced in AutoCAD 2008)
    --Recovers a selected drawing file
    --Attached and nested xrefs are also opened, repaired, resaved, and closed
  • INSERT and EXPLODE
  • Start a new DWG with no template
    --Run INSERT and selected the corrupted drawing
    --Check the “Explode” option

If a file can be opened but still shows signs of corruption, take the following steps:

  • RECOVER and AUDIT
  • PURGE command
  • Copy and Paste into a new drawing
  • AECTOACAD (-EXPORTTOAUTOCAD)
    --Exports to a pure AutoCAD file in selected drawing version
    --Strips potentially corrupt custom objects
  • WBLOCK command
    --Set all layers ON, THAWED and UNLOCKED
  • WBLOCK all objects in the drawing to an external block file
  • INSERT the resulting file as block into a new drawing (check the “Explode” option or EXPLODE the block after inserting)
  • AUDIT and PURGE
  • DXFOUT/DXFIN
    --DXFOUT to create a new .dxf file
    --Start new drawing and DXFIN to import the new .dxf file
    --Also try exporting as AutoCAD 12 DXF
  • XREF into a new drawing and BIND

See also Recover damaged drawing when RECOVER command not successful - TS19369

  • Using Windows Explorer or the Windows Find feature, search the entire hard disk for autosave (SV$) files or backup (BAK) files with the same name as the drawing. Rename those files so that they have a DWG extension, and you may be able to open them. (By default, SV$ files are in the %TEMP% folder and BAK files are in the same directory as the DWG file.)
  • Use WBLOCK command to insert the corrupt drawing into a new drawing. Insert at the 0,0,0 coordinate.
  • Open the drawing in a previous release of the software, if available (AutoCAD only).
  • Export the drawing as a DXF™ file, then import the DXF file.
  • If the drawing was last saved in an older format, try using partial open to load the drawing one layer at a time until you find a layer containing an error. Then repeat, skipping that layer next time. See related documents for instructions on using the partial open feature (AutoCAD only).

Drawing Recovery Manager (command DRAWINGRECOVERY)
Displays a list of all drawing files that were open at the time of a program or system failure. You can preview and open each drawing or backup file to choose which one should be saved as the primary DWG file. After a program or system failure, the Drawing Recovery Manager opens the next time you start the application. Drawing Recovery Manager displays a list of all drawing files that were open. The System Variable RECOVERYMODE controls whether drawing recovery information is recorded after a system failure and whether to show the Drawing Recovery Manager or not.

If you want to help yourself, Autodesk and other AutoCAD users make sure to send in any errors to Autodesk when you see the Customer Error Report dialog box (CER).

Finally a solution that sometimes helps if AutoCAD cannot fix the problem is to try to fix the drawing in another program that can open and save DWG files. The more users having the similar problem the better chance it will be fixed in a service pack or future version. Eventually you might get an email saying the problem is fixed.

You may find JTB World’s SmartPurger useful to batch process drawings that needs to be fixed. It includes Audit and Purge functionality as well as a lot more.

Friday, December 13, 2013

Autodesk tips, tricks and news like the AEC Feed

AEC Feed keeps you up-to-date on AEC industry news, trends and the latest updates from your favorite Autodesk AEC software products. You can download the app from Apple App Store (note: iPad 6.0 or higher required). Via Beyond Design

Autodesk University 2013 has ended and the Recorded streams of keynotes, forums and some classes are available if you missed it live or online.

FLEXnet Licensing error:-15,10 when performing Status inquiry on LMtools - TS22754152
Issue: FLEXnet Licensing error:-15,10. System Error: 10049 "WinSock: Invalid address" When performing Status Inquiry on LMtools.
Windows firewall interfering with license server

Educational Watermarks [Plot Stamp] + AutoCAD 2014 SP1. Please be very cautious when using an Educational version of AutoCAD 2014 SP1.  There is a STILL an EDU watermark [plot stamp] but the warning is now suppressed in SP1. - via Up and Ready
Check also out EduFinder by JTB World to find and identify AutoCAD drawings (DWG) that contain the educational stamp.

Stability issues and unexpected exit when you click on a command in the contextual ribbon tab in Autodesk Revit - TS22753368
Customers have been able to solve this issue by updating the WACOM drivers installed on the system.

Some map features are not labeled - TS22745944
Although you've created labels in the Style Editor, many features do not display their labels. Applies to AutoCAD Map 3D and AutoCAD Utility Design.

QSAVE does not work because AutoCAD considers the drawing to be read-only - TS22745933
Suddenly you are unable to save an open drawing because AutoCAD considers the file as read-only. The drawing you are working with is saved on a network. Applies to: AutoCAD Map 3D 2014

Extraneous spatial data types showing in Style Editor in AutoCAD Map 3D/AutoCAD Civil 3D - TS22757634

Cannot select schema in Bulk Copy target field in AutoCAD Map 3D - TS22754136

FDO connection still shows Oracle feature classes in Map 3D that were removed - TS22754647

Error: "Failed to create the Data Source file" when trying to Attach Access Database in Map 3D - TS22754416

Dialog box for Define Query does not appear in Map 3D (ADEQUERY command) - TS22753406

Productstream Professional 2011 Client Update for Windows Internet Explorer 10 - DL22757907

Strange graphics behavior and frequent crashing on launch of AutoCAD - TS22754147
Issue: Your AutoCAD-based product either crashes while launching, or when AutoCAD loads,or you notice abnormal behavior in the user interface.
Symptoms: AutoCAD launches but then immediately crashes.
The AutoCAD dmpuserinfo.xml file shows "32-bit" within the <DisplayMode> tag, even though your system is 64-bit.
If AutoCAD launches successfully, and you switch to a Classic workspace, some of the tools and tabs disappear from the user interface.
A repair and/or reinstall of AutoCAD has not resolved the issue.

When I try to install I get an Internal Error 2738 (this can apply to many different Autodesk products) - GS22754600

Objects not visible after zoom extents in AutoCAD - TS22757632
In paper space, the xref and other drawn entities are shown. While in the model space, none of the objects are visible. Performing a zoom extents results in multiple small dots appearing. While trying to zoom to one of these dots, nothing is showing and you cannot see the xref or other drawn entities.
Cause: Objects in the drawing were grouped far away.

Zero upstream distance error for Culvert model in River and Flood Analysis in AutoCAD Civil 3D 2014 - TS22757720

Zoom to profile view does not work in River and Flood Analysis Module in AutoCAD Civil 3D 2014 - TS22757610

Thursday, December 5, 2013

Autodesk Structural Bridge Design and other Autodesk news

Here’s some recent Autodesk news:

  • Autodesk Dynamo and Autodesk FormIt Updates– For building designers, Autodesk announced a major update for computational design with the merger of Autodesk Dynamo and Autodesk DesignScript. Dynamo is an open source visual programming environment for BIM. It can be used stand-alone, or allows users to extend the parametric capabilities of Autodesk Revit software products. Autodesk DesignScript is a unique programming language, intended to help designers build and analyze complex geometric models that would be difficult to model with interactive techniques. Now both are coming together in Dynamo to deliver a clear confluence of the best of both worlds: a clean and modern UI that combines DesignScript responsiveness and visual feedback with Dynamo's tight integration with Revit.


    Also today, Autodesk announced that the BIM-based conceptual design tool, Autodesk FormIt, now includes a web-based application that runs on a choice of browsers for Windows and Mac (currently available in beta at autodeskformit.com). On all platforms – including previously released iPad and Android versions – Autodesk FormIt gives architects and designers easy-to-use tools to create, collaborate and share early-stage design ideas and continue their BIM process by taking models straight into Autodesk Revit. FormIt for iPad has been updated to take advantage of iOS 7 and also includes new energy analysis features that enable users to get simple indications of potential building performance – valuable insight at the beginning of the BIM process that can reduce rework later.
    Looking ahead, Autodesk demonstrated a forthcoming feature in the FormIt family of applications that supports real-time collaboration, enabling future designers to simultaneously access and collaborate on design models using their FormIt application of choice.
    For more on the Dynamo and FormIt updates, please see a related blog post here.

  • Graitec Acquisition – Expanding its capabilities in the structural detailing stages of BIM, Autodesk also today announced the close of its acquisition of Graitec’s Advance Steel and Advance Concrete product lines and associated employees. Building on Autodesk’s current portfolio for structural engineering, the acquired product lines offer modeling, detailing, and fabrication solutions to support BIM-based steel and reinforced concrete workflows.

  • Autodesk Structural Bridge Design - For bridge designers and engineers, Autodesk recently launched Autodesk Structural Bridge Design. Resulting from the August acquisition of technology assets from UK-based Bestech Systems, the new software is an important addition to the Autodesk BIM for infrastructure portfolio. Autodesk Structural Bridge Design gives engineers greater flexibility and efficiency in their small- to medium-span bridge design processes by integrating loading, analysis and code checking in a single environment. By using this unique approach, more consistent data can be used throughout the bridge design process allowing projects to be more quickly and accurately brought to completion. For more on Autodesk Structural Bridge Design, please see a related blog post here.

    Autodesk Structural Bridge Design

  • Azalient Technology Acquisition - Also today Autodesk announced the acquisition of technology assets from UK-based Azalient Ltd. The acquisition helps support the evolution to BIM-based design workflows among traffic engineers and transportation planners working on roads, highways and railway projects. The acquired traffic analysis technology enables designers to simulate how people travel - whether by automobiles, busses or trains - in isolation and in series. It also provides transportation customers with tools to help predict demand for new infrastructure projects, forecast how to handle future demand and predict traffic disruptions caused during construction, with the addition of cost and benefit analysis of alternative infrastructure designs. Terms of the acquisition were not disclosed.

  • Topcon Collaboration – Building upon Autodesk's existing collaboration with Topcon, the two companies are working together to further improve the integration of BIM workflows and field layout to support greater predictability, productivity and profitability. Autodesk is developing a new BIM 360 mobile app for iPad that further simplifies the process of precisely locating BIM coordinates on a construction site. Designed for general contractors and MEP trades, the app controls a robotic total station – as well as the new LN-100 3D positioning system from Topcon announced yesterday - that can accurately position control and layout points on the construction site, and as-built data can be fed back into the design model via BIM 360 for quality assurance.

And finally a workaround tip: Performance issue and flickering in AutoCAD LT 2014 when panning and zooming - TS22742730
While working with certain drawings in AutoCAD® LT 2014, the program runs slow and the status bar flickers, especially with multiple files open, even with basic commands such as panning and zooming.

Monday, November 25, 2013

Autodesk support for Windows XP ends in 2014 and other Autodesk news

Here’s some recent news from Autodesk:

Autodesk Community has been updated. Check it out the new look.

123D Catch 2.0 for iOS makes 3D photography and model creation epically better.
Guided capture tools give you dynamic feedback as you take your photos.
The new gallery provides a streaming showcase of captures from around the world.
And underneath the hood is an entirely new pipeline that makes better, faster, more amazing 3D models. More here.

Microsoft Windows XP support for AutoCAD products FAQ - GS22683753
Autodesk support for the Microsoft Windows XP operating system ends on January 1, 2014 for all new and upgraded versions of AutoCAD products released in 2014 and later. Versions of AutoCAD products (AutoCAD, AutoCAD LT, AutoCAD Architecture, AutoCAD Electrical, AutoCAD Map 3D, AutoCAD Mechanical, AutoCAD MEP) released prior to January 1, 2014 will continue to be supported on the Windows XP operating system.

The Revit 2014 Daylighting Analysis (RDA) plug-in uses the Autodesk 360 Rendering cloud service to perform very fast and physically accurate daylighting analyses from within Revit. More here.

Hotfix - Autodesk Inventor 2014 (Polish only) Flat pattern text parameters missing - DL22712527

Revit LT 2014 Update Release 2 - DL22607186

Friday, November 15, 2013

Autodesk updates and news like Smithsonian x3D Explorer

Hotfix - Inventor unexpectedly exits after updating to Windows 8.1 - DL22541232

AutoCAD 2013 for Mac Service Pack 2, This update resolves compatibility issues on the new Mac OS X Mavericks and more - DL22614738

AutoCAD LT 2013 for Mac Service Pack 2 - DL22617033

From the Press release: Autodesk and the Smithsonian today debuted the Smithsonian x3D Explorer, an interactive 3D educational tool accessible to anyone via the web. Autodesk built the tool exclusively for the Smithsonian to democratize access to prized specimens and to bring their stories to life. The public can now experience priceless objects digitized by the Smithsonian like never before, from seeing “behind the glass” to holding 3D printed replicas.

Here’s a detail from 1903 Wright Flyer:

Tuesday, November 12, 2013

JTB Sheet Set Creator app for AutoCAD

JTB Sheet Set Creator is an add-in for AutoCAD from JTB World that creates new Sheet Sets and Sheets based on an Excel template. If you often create new Sheet Sets JTB Sheet Set Creator can save you a lot of time and efforts.

  • Sheet Set Properties can be populated.

  • Sheet Set Custom Properties can be defined, created and populated.

  • Sheet Properties can be populated.
  • Sheet Custom Properties can be defined, created and populated.

  • Sheets (drawings) can be defined, created and have their properties populated.

When ready the Sheet Set can be opened within AutoCAD.

Download trial and learn more about this app on the JTB Sheet Set Creator page. JTB Sheet Set Creator Trial can also be downloaded and installed as an app from the Autodesk Exchange Apps site.

JTB World also have these AutoCAD Sheet Set related apps. SSMPropEditor, DST converter and Sheet Set Manager Path Edit

If you are interested in other useful AutoCAD helper functions take a look at DigSigStamp, Batch Publish for AutoCAD, DimensionPatrol, TransTips or OffsetInXref.

Friday, November 8, 2013

Revit in a browser and other Autodesk news

Here’s some recent news from Autodesk:

  • Autodesk Provides 3D Design in a Browser via press release and with some comments by Shaan. Collaboration with Amazon Web Services, OTOY and NVIDIA Enables Developers to Access Powerful 3D Modeling from Anywhere, Anytime, with Any Device Using a Simple Web Browser. Even though the press release says it’s available now I don’t find it available yet to test.
  • Autodesk Vehicle Tracking Product Center is Autodesk’s Vehicle Tracking software based on AutoTrack that was acquired by Autodesk. It is a transportation analysis and design solution for vehicle swept path analysis that helps to predictably evaluate vehicle movements on transportation or site design projects.
  • Project Shapeshifter Now Available via Autodesk Labs. See this post.
  • Hotfix - Hebrew language is switching backward while printing and print preview - DL22524059
  • Update 3 for Inventor 2013 Service Pack 2 - DL22436649
  • Hotfix - Frame Generator length results are inaccurate - Inventor 2012 - DL22499412
  • Hotfix - OnPopulateFileMetadata suggests same name for different occurrences in Copy command - Inventor 2012 - DL22499409

See also Revit 2014's Web Update Release 2 and other Autodesk updates

Thursday, November 7, 2013

DigSigStamp digital signatures stamp app for AutoCAD

JTB World’s DigSigStamp for AutoCAD allows you to specify a block that will change its display when plotted to indicate whether the drawing had a valid digital signature at the time of plotting.

The DigSigStamp AutoCAD plugin helps you identify visually when drawings have valid digital signatures. You use one of the plugin's commands to specify blocks to display when a drawing has a valid digital signature and when it does not. You then assign a particular block reference - which usually exists in the title block of your drawing - that will change its display to one of these two block definitions depending on the state of the drawing. The application even works when plotting, an operation that typically invalidates a drawing's digital signature.

The following are just examples of how the blocks can look like. The design of them is completely up to you. Digitally Signed example. This drawing has a valid digital certificate.

Invalid. This drawing does not have a valid digital certificate.

Unverified example. Digital signature verification application is not enabled.

DigSigStamp can be further customized by JTB World to fit your specific needs and requirements.

Download a trial and learn more on the DigSigStamp web page as well as on Autodesk Exchange Apps site.

If you are interested in other useful AutoCAD helper functions take a look at Batch Publish for AutoCAD, DimensionPatrol, TransTips or OffsetInXref.

Tuesday, November 5, 2013

Revit 2014's Web Update Release 2 and other Autodesk updates

Revit 2014's Web Update Release 2 is available.

Autodesk® Revit® Platform 2014 Enhancements
 Disables the ability to paste spot elevations into a Sketch mode.
 Improves stability when using Results and Compare for Energy Analysis.
 Improves stability when exporting to AutoCAD 2000 DWG format.
 Improves Online Help experience by properly redirecting help inquiries to Autodesk Help.
 Improves stability when enabling Sun Path.
 Improves graphic display of Analytical Model Walls.
 Improves data integrity of user defined parameters when utilizing temporary view templates.
 Improves stability when editing dimensions.
 Improves upgrade reliability of projects created with a different language version of Revit.
 Improves stability when selecting materials within the Material Browser.
 Restores the appearance of area color fills within linked files, when setting the view as By Linked View.
 Improves stability when upgrading projects which utilize Keynotes.
 Improves stability when importing IFC files.
 Improves stability when editing Filters within the Visibility/Graphics Overrides dialog.
 Improves stability when saving projects which were upgraded.
 Improves stability when combining Phases.
 Improves accuracy of Analytical Volumes.
 Improves display of Imported Categories for DWG files linked into the project using the “Current View Only” option at time of import.
 Improves stability when attempting to turn on sun path while temporary view properties mode is active.
 Improves data integrity when export model to FBX.
 Improves display of hidden lines on walls in Floor Plan and Elevation views.

Autodesk® Revit® MEP 2014 Enhancements
 Improves the visual fidelity of point clouds in MEP discipline views in regards to underlay elements in the view.
 Improves connection reliability between fittings when upgrading MEP projects.
 Improves connection reliability between fittings when changing the size of MEP elements.
 Improves the data integrity of the Outside Air per Area value for a HVAC when exported to gbXML.
 Removes the “Multiple Values” values for Flow, Velocity and Friction parameters and replaces it with the highest value applied to the entire segment length.

Autodesk® Revit® Structure 2014 Enhancements
 Improves display of vertical rebar when the rebar extends past the View Range.
 Improves the location consistency of Structural beams when upgrading projects.
 Improves stability when viewing a sheet which contains Structural Reinforcement Areas.

And here are some more Autodesk updates.

  • Update 1 for Inventor 2014 Service Pack 1 - DL22436654
  • Hotfix - Custom OE derived from a simple AutoCAD entity class - DL22520257
  • Navisworks 2014 SP1 NWF Refresh Hotfix - DL22506086
  • Hotfix - Autodesk Revit LT 2013 - Spot Elevation - DL22511641
  • While installing Inventor 2013 or Inventor 2014 you might get a dialog box with a red X and the text PLACEHOLDER and the installation fails. The only solution is uninstall the the Avast software before installing Inventor. - Up and Ready

See also this recent post about Windows 8.1 and Autodesk products.

Wednesday, October 23, 2013

AutoCAD 2014 for Mac and AutoCAD LT 2014 for Mac

AutoCAD 2014 for Mac and AutoCAD LT 2014 for Mac were released October 22, 2013.

AutoCAD 2014 for Mac

Retina display support is of course a much welcome news. The right side of the image shows what it look like now compared to before on the left side.

AutoCAD 2014 for Mac Retina display support

Autodesk 360 Sync for your drawings and design files. On a Mac, Autodesk 360 support only includes file sync.

AutoCAD 2014 for Mac drawing sync

Compress, store, and distribute CAD for Mac files with “Package Drawing” that is similar to eTransmit as it is called in AutoCAD for Windows.

AutoCAD 2014 for Mac package drawing

Other news are Autodesk Exchange Apps, Secure load (enhances software security and helps prevent loading and running “unauthorized or malicious” AutoLISP applications), it’s now possible to set a default save-as version for your drawings in OPTIONS, ZeroDocWindow option in General tab, FIND command fixes, usability enhancements, including a new online help homepage, a reworked welcome screen, a print dialogue preview button, detailed print dialog panel expanded by default and of course support for OS X Mavericks.

The online Help Search is not working yet. (UPDATE. I have been contacted by Autodesk and informed about that the issue with the Help Search has been solved.)
http://docs.autodesk.com/ACDMAC/2014/ENU/index.html

A lot of AutoLISP documentation updates have been made. More on Lee’s blog post.

Function Listing (by Name and Feature) - Provides you with access to AutoLISP functions not only by alphabetic names but also by feature classification.

AutoLISP Developer's Topic Map - Listing of all essential topics in one page.

Gone is the separate Windows and Mac AutoLISP documentation, the function reference topics now call out what platform they are supported on.

New Commands

The following commands were added:

ETRANSMIT Packages a set of drawings and dependency files into one unit for sharing.

-ETRANSMIT From the Command line, packages a set of files for sharing.

ONLINESHARE Designates who can access the current drawing from Autodesk 360.

ONLINEOPENFOLDER Opens your local Autodesk 360 folder in Finder.

Changed Commands

The following commands were changed:

PLOT Plots a drawing to a plotter, printer, or file.

OPTIONS Customizes the program settings

WELCOMESCREEN Displays the Welcome window when you start the program.

NEWSHEETSET Creates a new project data (DST) file that manages drawing layouts, file paths, and project information.

FIND Finds the text that you specify, and can optionally replace it with other text.

New System Variables

The following system variables were added:

ONLINEUSERNAME Displays the username that is used to log into the Autodesk 360 account.

ONLINEDOCMODE Indicates whether a copies of your drawings and linked files are uploaded automatically to Autodesk 360.

ONLINEFOLDER Displays the location of your local Autodesk 360 folder in Finder.

SECURELOAD Controls whether AutoCAD loads executable files based on their location.

TRUSTEDDOMAINS Specifies the domains from which AutoCAD has permission to load and execute files that contain code.

TRUSTEDPATHS Specifies the folders from which AutoCAD has permission to load and execute files that contain code.

ONLINEUSERID Displays the ID associated with the Autodesk 360 backend system.

The feature comparison chart shows the differences between AutoCAD and AutoCAD for Mac.

The 30 day trial of Autodesk AutoCAD 2014 for Mac is now available at http://www.autodesk.com/products/autodesk-autocad/free-trial

If you have AutoCAD 2014 (for Windows) or the AutoCAD Design Suite your serial numbers works for the Mac version of AutoCAD 2014.

Customers can purchase AutoCAD 2014 for Mac or AutoCAD LT 2014 for Mac from the Autodesk Store, through CDW and Amazon, or from a local Value-Added Reseller.

AutoCAD for Mac is available worldwide in English and French.

AutoCAD 360, optimized for iPad Air and iPad mini with Retina display, will also be available on the App Store. On the new iPad, AutoCAD 360 opens files faster, and rendering and selection is also twice as fast.

Monday, October 21, 2013

AutoCAD app DimNotes 1.3 released

JTB World’s AutoCAD app DimNotes 1.3 has been released. The news are an added option to preset location and replace settings for each note individually as well as added option to use or not use space when the location is before or after. This makes it even quicker to add noted or comments to AutoCAD dimensions.

The note can be added Above, After with space, After without space, Before with space, Before without space or Below existing text. There is also an option "Replace" to completely replace the text so the associative dimension text is removed if the text is <>.

Location option Replace can be used to add both before and after the dimension. Say the existing dimension text is 28 and the note is (<>) the result will be (28). Even notes using control codes, Text Symbols and Special Characters like
\A0;<> {\H1.5x;}\A2;\H0.71x;%%p0.1 can be used with this result: 28 ±0.1.

Some examples with notes added before, after below or above.

DimNotes can also be downloaded and installed as an app from the Autodesk Exchange Apps site. Purchase is optionally available through this site as well as here.


Some of the latest blog posts

Subscribe to RSS headline updates from:
Powered by FeedBurner
